Characteristics:
• The middle woven mesh structure makes it have excellent sheath pushing ability and bending resistance;
• Thin-walled large cavity (0.088″ large inner diameter), effectively reducing vascular damage, reducing complications and compatible with more instruments;
• 5 transition zones from near end to far end, from hard to soft, taking into account support and passability;
• The distal end is flexible and flexible, and the proximal end is super supported; the transition areas are seamlessly connected without damage to blood vessels;
• The surface is coated with clear water to reduce puncture resistance and to easily achieve sheath placement;
• The dilator is included in the package, which can be used independently without the 8F short sheath;
Manufacturing Experience:
• ID：2.25mm; OD：2.72mm； L: 80cm Working Length
• 5 Transition zones from Proximal to Distal end
• Matching Dilator
Configuration and Main Components:
• Inner Side: PTFE Liner
• Middle Layer: Stainless Steel Flat or Round wires
• Outer Jacket: Multi Section of TPU + Pebax + Pebax + Pebax + PA
• Hydrophilic Coating
